GG-NO2 Nitrogen Dioxide Gas Detector

Name: Calibration Technologies
Address: 920 N. Tradewinds Pkwy, Columbia, MO, 65201, United States
Telephone: 8663945861

Industrial Gas Sensor for Nitrogen Dioxide (NO2)

Enclosure

Sensor Element

Clear

Downloads

GG Datasheet (all gases)

GG-NO2 brochure

GG-NO2 manual

Product Details

Specifications

Equipment Options

Related Products

GG-CO2 Carbon Dioxide Gas Detector

GG-VL2 Vent Line gas detector

GG-NH3 Ammonia Gas Detector

GG-R Synthetic Refrigerant Gas Detector

GG-CL2 Chlorine Gas Detector

Enclosure	Polycarbonate: Injection-molded, NEMA 3RX washdown duty, with hunged lid and captive screw Stainless Steel: 18 GA, NEMA 3RX washdown duty, with hinged lid and captive screw
Dimensions	7.7″ H x 6.7″ W x 3.8″ D
Wiring Connection	3-conductor, shielded, stranded, ≥ 20 AWG cable (Belden 8772 or equivalent) up to 1500 ft
Terminal Block Plug (Field Wiring)	26-12 AWG, torque 4.5 lbs-in
Output Signal	4-20 mA linear output
Input Power	+24 vdc
Detection Method	Diffusion
Sensor Technology	Electrochemical
Response Time	T50: < 60 seconds \| T90: < 120 seconds
Accuracy	+/- 5%
Zero Drift / month	< 0.1% full scale
Span Drift / month	< 3% full scale
Linearity	+/- 0.5%
Repeatability	+/- 1% full scale
Operating Temperature	-4°F to +122°F
Operating Humidity	5-100% condensing
Certification	SGS listed to UL 61010-1, and CSA C22.2 No. 61010-1-12
Warranty	2 years sensing element and transmitter
